AC Power Meter with LCD (20A 80-260V)

Simultaneously displays AC voltage, current, power, and energy on a large back-lit LCD screen. Capable of measuring between 80 to 260VAC up to 20A, making it ideal for monitoring energy usage for large appliances such as a refrigerator, dehumidifier, washing machine, air conditioner, etc. Also suitable for solar setups. Over-voltage and power alarms can also be set.

Features:

• AC Voltage, Current, Power, and Energy
• Measure between 80 - 260VAC up to 20A

Product Specifications

• Screen Type : Flat Panel Screen (LCD)
• Screen Backlit : LED Backlit
• Screen Width : 51.0mm
• Screen Height : 30.0mm
• AC Current Ranges : 20.0A
• Instantaneous Power Ranges : 4500.0W
• AC Volts Measurement Range : 80.0V, 260.0V
• Dimension details : Main Unit
• Width : 90.0mm
• Height : 50.0mm
• Depth : 24.0mm
• Weight : 60.0g
• Dimension for : Display Screen
• Width : 51.0mm
• Height : 30.0mm
• Dimension details : Cutout Dimensions
• Width : 84.6mm
• Height : 44.6mm

• Length : 15 cm
• Width : 8 cm
• Height : 3 cm
